Hot sell High Pressure Hydraulic Hose Crimping Machine Air
Suspension 220V 380V
| Position | Metal Ring | Mold size |
| A6 C5 Front Upper- A6 C5 | 125*119*12 | 118*15 |
| A6 C5 Front Lower- A6 C5 | 101*95*10 | 96*15 |
| A6 C5 Rear Upper- A6 C5 | 107*101*15 | 100*15 |
| A6 C5 Rear Lower- A6 C5 | 98*92*13 | 88*15 |
| A6 C6 Front Upper- A6 C6 | 135*129*10 | 128*11.5 |
| A6 C6 Rear Upper- A6 C6 | 115*110*10 | 105*12 |
| A6 C6 Rear Lower- A6 C6 | 100*95*10 | 94*12 |
| A8 D3 D4 Front Aluminum Cover - A8D3 | | 125 |
A8 D3 Front Lower
A8 D4 Front Lower
E65 E66 Rear Lower A6 C6 Front Lower Jaguar Front Lower/ Rear
Lower- A8 D3 | 93*88*10 95*89*10 94*88*10 94*88*10 92*87*9 | 88*11.5 |
A8 D3 Front Upper
A8 D4 Rear Upper- | 131*125*10 136*130*10 136*130*10 | 126*12 |
| A8 D4 Front Upper- A8 D4 | | 123*12 |
A8 D3 Rear Upper-
A8 D3 | 131*125*15 | 122*15 |
A8 D3 Rear Lower
F02 Rear Lower
Q7 Old Front Lower
Q7 Old Rear Lower- | 99*93*14 99*93*14 99*95*14 100*95*15 | 92*15 |
| A8 D3 Rear Plastic- | | |
| A8 D3 Rear Aluminum cover | | 125 |
Front Upper- Q7 old model,
Front Upper- Q7new model | 152*145*15 155*147*15 | 142*15 |
| Front Aluminum Cover-Q7 old model | | 140 |
| Q7 old model /new model Front Plastic Tooling | 140*132*10 142*134*10 | |
| Q7 old model /new moel Rear Plastic Tooling | 132*122*10 132*122*10 | |
| Q7 old model Rear Upper Q7new model Rear Upper | 145*137*15 | 136*15 |
| Q7 Old Rear Aluminum Cover Q7 New Model Front/Rear Aluminum Cover | | 135 |
| Front Lower,Rear Lower- Q7 new model | 105*99*15 | 90*.15 |
| W220 Front Upper | 136*130*10 | 127*10.5 |
| W220 Front Aluminum Cover | | 137 |
| W220 Rear Upper | 109*103*10 | 102*12 |
W220 Front Lower
W220 Rear Lower,
W211 Front Lower | 97*92*10 | 92*12 |
| Front Lower-W164,W251 | 111*106*14 | 100*15 |
| Front Upper-W164,W251 | 139*133*14 | 129*15 |
| Rear Lower-W164,W251 Jeep Grand Cherokee Rear Lower | 113*107*13 | 105*15 |
| Rear Upper-W164,W251 | 141*135*13 | 130*15 |
| W211 Rear Upper and Lower | 109*105*10- | 102*12 |
| W221 Front/ Rear Upper | 139*133*10 | 130*10.5 |
W221 Front Lower W221 Rear Lower
A8 D4 Rear Lower | 101*95*10 100*94*10 | 95*10.5 |
| W221 Front and Rear Aluminum Cover | | 132 |
| W211 Front Upper | 134*128*10 | 122*12 |
W166 Front Upper ring,
Jeep Grand Cherokee Rear Upper | 146*140*11 147*140*13 | 136*12 |
| W166 Front shock aluminum cover | | 135 |
| W166 Front Lower | 112*106*11 | 104*12 |
| W212 Rear Upper Ring | 117*110*11 | 103*12 |
Features
1. It is mainly used for crimping processing all kinds of high
pressure industrial hose / tube assembling, agricultural hose /
tube processing, oil hose / tube assembling in mechanical
engineering. The machine is widely used in crimping for air
suspension springs ,air suspension shocks,Lower noise and lighter on weight .
2 . We can provide220V and 380 V input voltage for different
countries requirements
3 . Special Pump Design, fast crimping and Simple Operation and easy maintenance .
4 . Optimal Combination of technical effect and economical profit
in die design
5. We provide free training for all customer if necessary
6. We will provide one year warranty time for the crimping machine
Parameters
Voltage: 380 V
Power: 3 KW
Pressure of System: 32 MP
Operate mode: auto, manual, pedal
Die Sets: 10 sets customized sizes
Power of Crimping: 300 Tons
Demension(L*W*H): 77*87*121 CM
Weight: 350 kgs
Packing: Wooden Case and Pallet
Range of crimping: 50-168 mm
Accuracy: 0.05 mm
Details of machine
1. About Diets or mould .
When you buy the machine, we have 10 sets of free diets for gift,
the sizes of which are according to the air suspension shock models
you want to crimp.
2. About Operation
It's easy to operate.we have complete English operating manual and
operating CD to offer for you. Also we have technical support team
available to train you how to use the machine.
3. About Warranty period
We offer a one year warranty for the machine.
4. About Voltage
Our standard voltage is 380 V,but we could change according to your
special requirment.
5. About Application
It can be used to repair or remanufacture air suspensions, air
aprings for cars and trucks. and aslo the industrial hydraulic hose
pipes.
About Us
1) We have 4 our own factories and we are keep producing goods with
strict qualtiy control and test each item before they are shipping
out.
2) We have more than 14 Years experience of manufacturer of Air
Suspension Shock System and we will provide free training for all
of our customer.
3) We have strong R & D team is keep improving our quality and
design. And developing new products every season. We are keeping
both comfortable driving and safe driving in mind.
We are offering techinal support and technical training to help our
clients .
